ZJ744X Mud Valve

ZJ744X mud valve designed by Dazhong Valve Group, the valve is composed of double-chamber diaphragm (piston) transmission mechanism and angle-type globe valve. The valve disc of the valve is sealed with rubber, which can close tightly without leakage, open smoothly and quickly, with little movement and wear, and is not sensitive to sediment deposition. It is suitable for water companies and various pools. For interception.

• The valve consists of a double-chamber diaphragm (piston) transmission mechanism and an angle-type globe valve.

• Hydraulic and pneumatic angle-type quick-opening sludge discharge valves are mainly used in water companies and various pools to remove sediment or dirt at the bottom of the pools. It can also be installed when the working medium is water, gas and oil. It can be used for interception in industrial pipelines.

• The valve disc of this valve is sealed with rubber, which can close tightly without leakage, open smoothly and quickly, with little movement and wear, and is not sensitive to sediment deposition. It is easy to install and maintain.

• The driving medium can use tap water directly, no other power source is needed, and the operation is convenient.

• The electric head drives the gate to open or close. It can also be opened or closed manually when the power is off. One valve can be opened or closed with two types. After closing, it has the advantages of good performance and no leakage.
