YZ11 Type Direct Acting Pressure Reducing Valve

The YZ11 type direct acting pressure reducing valve designed by Dazhong Valve Group is mainly composed of valve body, valve cover, compression spring, diaphragm, stirrup clamp and valve disc. Its main features: reliable performance, durable. It is resistant to dirt and scale, no filter, no bypass pipe, and the piping is extremely simple, which can save a lot of cellar and cost.

• The YZ11X, YG11X, YG41 direct-acting pressure reducing valve series products produced by our group are mainly composed of valve body, valve cover, compression spring, diaphragm, stirrup clamp and valve disc and other parts.

• Its main features: reliable performance and durability.

• Resistant to dirt and scale, no filter, no bypass pipe, the piping is extremely simple, which can save a lot of cellar and cost.

• The outlet pressure is precisely adjustable. In general, the outlet pressure is not affected by the inlet pressure (the change of the outlet pressure is 8% of △P1). Excellent hydraulic characteristics can meet various decompression requirements. , especially suitable for branch pipe decompression system.
