Y13X Fixed Proportional Pressure Reducing Valve

The Y13X-16 all-copper proportional pressure reducing valve designed by Dazhong Valve Group is mainly composed of valve body, inlet gland, piston, outlet gland, O-ring, gasket and other parts. The valve uses the different cross-sectional areas of the floating piston in the valve to cause the pressure difference to change the pressure conditions of the inlet and outlet water to achieve the purpose of decompression.

• The Y13X-16 type all-copper proportional pressure reducing valve produced by our group is mainly composed of valve body, inlet gland, piston, outlet gland, O-ring, gasket and other parts

• This valve uses the different cross-sectional areas at both ends of the floating piston in the valve to cause a pressure difference to change the pressure conditions of the inlet and outlet water to achieve the purpose of decompression

• The product is rigorous in structure, novel in structure, smooth in operation, light in size, easy to install, and has a stable decompression ratio, which reduces both "dynamic pressure" and "static pressure". The material is made of copper, which is suitable for clean water and seawater , not afraid of scaling and rust

• The company provides standard pressure ratios of 2:1, 3:1, 5:1, 5:2, etc., and can design special proportional pressure reducing valves according to user requirements.
