Resilient Seat Gate Valve

Dazhong Valve Group's elastic seat gate valve, the overall bonnet and dark stem design, compact structure; two-body structure of stem nut and gate plate, no jamming phenomenon; straight channel, no leakage cavity; stem seal adopts O-shaped seal lock up. The reliable and hygienic epoxy resin conforms to the hygienic standard GB/T17219-1998. The gate plate is entirely covered with rubber that meets the hygienic inspection. The valve stem, stem nut and other parts are made of stainless steel or bronze that is not corroded by water.

• Integral valve cover with dark stem design, compact structure; two-body structure of stem nut and gate plate, no jamming phenomenon; straight channel, no leakage cavity; stem seal adopts "O" ring seal

• It has excellent anti-corrosion performance. The inner and outer surfaces of the shell are sprayed with epoxy resin, and the inner surface is lined with enamel when necessary; the connecting bolts are made of hexagon socket bolts, and the top is sealed with rubber

• Reliable hygienic epoxy resin conforms to the hygienic standard GB/T17219-1998, the gate is entirely covered with rubber that conforms to hygienic inspection; the valve stem, stem nut and other parts are made of stainless steel or bronze that is not corroded by water, etc. Material.

• Suitable for drinking water, water supply and drainage, sewage treatment, natural gas and gas, industry and food industries.
