HQ41X Check Valve

The HQ41X check valve designed by Dazhong Valve Group uses a rubber-covered ball as the valve disc. Under the action of the medium, it can roll up, down, left and right on the integral slideway in the valve body to open or close the valve. Muffler closing, no water hammer, good sealing performance. The valve body adopts a full water flow channel, with large flow, small resistance, and 50% less head loss than the swing type. Vertical installation, it can be used in cold water, hot water, industrial and domestic water pipe network systems, more suitable for submersible sewage pumps, and the medium temperature is 0~80°C.

• HQ41X, HQ44X ball check valve and HQ45X multi ball check valve produced by the group.

• The rubber-covered ball is used as the valve disc. Under the action of the medium, it can roll up, down, left and right on the integral slideway in the valve body to open or close the valve.

• Muffler closing, no water hammer, good sealing performance. The valve body adopts a full water flow channel, with large flow, low resistance, and 50% less head loss than the swing type.

• Vertical installation, it can be used in cold water, hot water, industrial and domestic water pipe network systems, more suitable for submersible sewage pumps, and the medium temperature is 0~80°C.
