200P Type Pressure Reducing Valve

The 200P type pressure reducing Dazhong Valve Group by Dazhong Valve Group is connected with internal threads and consists of a valve body, a valve cover, a compression spring, a valve stem and a diaphragm. It is more secure and reliable.

• The 200P type pressure reducing valve produced by our group is connected with internal thread and consists of valve body, valve cover, compression spring, valve stem and diaphragm, etc.

• A structure in which the pressure after the valve is directly transmitted to the underside of the diaphragm and maintains the best balance with the pressure above the diaphragm.

• It has the characteristics of sensitive action, fast, reliable performance, long service life, small size, and easy installation.

• A filter screen is attached inside, which is convenient for overall installation and avoids clogging of debris, making it safer and more reliable.

• It can be installed horizontally or vertically in water supply, fire protection systems and other systems. The outlet pressure of the valve can be controlled to a relatively fixed value within a certain flow range.
