ZDLY Electronic Electric Small Flow Regulating Valve

ZDLY electronic electric small flow regulating valve produced by Dazhong Valve Group, ZDLY electronic electric micro flow regulating valve is a small diameter regulating valve specially developed for micro flow regulation. When adjusting the unclean medium, the problem of small throttling gap should be paid attention to to prevent the occurrence of jamming.

• ZDLY electronic electric micro-flow regulating valve is a small-diameter regulating valve specially developed for micro-flow regulation. When the medium is used, the problem of small throttling gap should be paid attention to to prevent the occurrence of jamming. The electric small flow control valve is suitable for the main flow adjustment of liquid, steam and other media. For example, it is used in precision chemicals and scientific research institutions. Precise micro-control of flow and pressure.

• ZDLY electric small flow control valve is composed of 3810 series PSL series electric actuator and small flow control valve body. The current signal is converted into the corresponding linear displacement, and the opening of the regulating valve is automatically controlled to achieve continuous adjustment of the process parameters such as the pressure, flow, temperature, liquid level, etc. of the fluid in the pipeline.
