ZDLS Electronic Electric Angle High Pressure Regulating Valve

The ZDLS electronic electric angle high pressure regulating valve designed by Dazhong Valve Group is composed of PS series and 3610 series straight stroke electric actuators and low flow resistance straight through single seat valve. The electric actuator is an electronic integrated structure, and the angle-shaped high-pressure control valve is designed for the control valve to have a short life under severe conditions of high pressure or high pressure difference, severe cavitation and erosion, the valve stem is easy to break, and the bushing is easy to fall off seriously. Problems developed products. The valve body is right-angled, and the valve core is a single-guide structure. The valve body has a simple flow path and low resistance. It is especially suitable for the adjustment of high-viscosity fluids containing suspended solids and granular media, which can avoid coking, sticking and clogging.

• ZDLS electronic electric angle high pressure regulating valve is composed of PS series and 3610 series straight stroke electric actuators and low flow resistance straight through single seat valve.

• The electric actuator is an electronic integrated structure with a servo amplifier inside. The valve opening can be controlled by inputting the control signal 4-20mADC or 1-5VDC and the power supply to achieve accurate pressure, flow, liquid level, temperature, etc. Adjustment of working parameters.

• It has the characteristics of sensitive action, simple connection, large flow, small size and high adjustment accuracy.

• The angle-shaped high-pressure regulating valve is a product developed for the serious problems of short life, easy breakage of the valve stem, and easy detachment of the bushing under the severe working conditions of high pressure or high pressure difference, severe cavitation and erosion. .It adopts multi-stage throttling form to share the pressure difference, reduces cavitation, erosion and torsion damage, greatly improves the service life of the regulating valve, especially in the urea system, the service life is increased by 2-3 compared with the ordinary high-pressure valve times.

• The valve body is a right angle, the valve core is a single guide structure, the valve body flow path is simple, and the resistance is small. It is especially suitable for the adjustment of high viscosity fluids containing suspended solids and granular media, which can avoid coking and sticking. , blocked.
