ZDLN Electronic Electric Double Seat Control Valve

Dazhong Valve Group ZDLN electronic electric double-seat control valve, ZDLN electronic electric double-seat control valve is composed of 3610L electronic electric actuator and straight-through double-seat valve. The electric actuator is equipped with a servo system, and no additional servo amplifier is required. , input 220VAC power supply and 4~20MaDC signal, you can control the valve opening, so as to achieve continuous adjustment of process parameters such as medium pressure, temperature, flow, liquid level, etc.

• ZDLN type electronic electric double-seat regulating valve is composed of 3610L type electronic electric actuator and straight-through double-seat valve. The electric actuator is equipped with a servo system, no need for additional servo amplifier, input 220V (AC) power supply And 4~20Ma (DC) signal, you can control the valve opening, so as to achieve continuous adjustment of process parameters such as medium pressure, temperature, flow, liquid level, etc.

• The product has the characteristics of sensitive action and convenient energy access. The signal transmission is fast, and it has the characteristics of small unbalanced force, large allowable pressure difference, and large flow coefficient. It is widely used in electric power, metallurgy, chemical industry, light textile and other industries. automatic control system.
