Q45F Flanged Three-Way Ball Balve

The Q45F flanged three-way ball valve produced by Dazhong Valve Group has T-shape and L-shape. The T shape can connect three orthogonal pipes to each other and cut off the third channel, so as to divide, merge and switch the flow direction of the medium. The L shape can only connect two pipes that are orthogonal to each other, and cannot maintain the interconnection of the third pipe at the same time, and only plays a distribution role.

• The three-way ball valve adopts an integrated structure in structure, the sealing type of 4-sided valve seat, less flange connection, high reliability, and lightweight design.

• The three-way ball core is divided into T-shaped and L-shaped, with long service life, large flow capacity and low resistance.

• The ball valve is divided into two types: single-acting and double-acting according to the action type. The single-acting type is characterized in that once the power source fails, the ball valve will be in the state required by the control system
