Q44F Flanged Three-Way Ball Valve
The Q44F flanged three-way ball valve produced by Dazhong Valve Group is designed and manufactured according to the national standard GB/T12237 with compact structure, rapid opening and closing, smooth flow passage and small fluid resistance. The four-sided valve seat material PTFE is elastically deformed to achieve leak-free sealing. After the system is depressurized, inspection and maintenance can be carried out without removing the entire valve body.
Q44F flanged three-way ball valve can be divided into L-type and T-type. L-type three-way ball valve is used for switching the flow direction of the medium, which can connect two channels that are perpendicular to each other. T-type three-way ball valve is used for medium Diversion, confluence and flow direction switching. T-type tee can connect three channels with each other or connect two of them.
Compact structure, quick opening and closing, smooth flow channel and small fluid resistance.
Good sealing performance, leak-free sealing is achieved by elastic deformation of the four-sided valve seat material PTFE.
One valve is used for multiple purposes, any port can be used as an inlet without leakage, and the tee can be made into either an L-shaped port or a T-shaped port. It is easy to maintain, after the system is depressurized, there is no need to Inspection and maintenance can be done by removing the entire valve body.
