D941X Electric Butterfly Valve

The D941X electric butterfly valve designed by Dazhong Valve Group adopts a middle-first type sealing structure, the valve seat and the disc are almost free of wear, and have a tighter sealing function. The sealing ring is made of stainless steel, the sealing surface of the butterfly plate is made of surfacing cobalt-based hard alloy, and the large-sized butterfly plate adopts a quilted frame structure. The drive device can be installed by rotating 90° or 180° in multiple positions, which is convenient for users to use.

• Small size: the volume is only equivalent to about 35% of similar products. The protection device has double limit, overheat protection, overload protection. The full travel time is 15 seconds, 30 seconds, 45 seconds, 60 seconds. And with manual Function.

• Easy to use: single-phase power supply, simple wiring; ball-shaped protruding structure, making observation more convenient; no fueling, no spot inspection, waterproof and rust-proof, and can be installed at any angle. Switch type electric butterfly valve with feedback signal Adopting the middle-type sealing structure, the valve seat and disc are almost free of wear, and have the sealing function of getting tighter and tighter.

• The sealing ring is made of stainless steel, which has the dual advantages of metal electric and elastic sealing. It has excellent sealing performance under low and high temperature conditions, and has the characteristics of long service life.

• The sealing surface of the butterfly plate is made of surfacing cobalt-based cemented carbide. The sealing surface is damaged and the service life is long. The large-sized butterfly plate adopts a quilted frame structure, which has high strength, large flow area and small flow resistance.

• The electric butterfly valve has a two-way sealing function. It is not restricted by the flow direction of the medium during installation, nor is it affected by the spatial position. It can be installed in any direction. The drive device can be rotated 90° or 180° in multiple positions, which is convenient for installation. User use.
